Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: ETCR
  • Model Number: ETCR025
  • Usage: Consumption Sensor
  • Theory: Current Sensor
  • Output: Digital Sensor
  • Test mode: Split Type CT
  • CT Size: 25mm(available for line $25mm)
  • Range: 0.000mA~60A (AC)
  • Accuracy: ±1.0%FS
  • Coils Turn: Standard 800:1(Customize is allowed)
  • Phase Error: ≤2℃(50Hz/60Hz; 23℃±2℃)
  • Output Interface: 3.5mm audio plug(tail plug, banana pin, or BNC pin)
  • Output Wire Length: 2m(Customize is allowed)
  • Weight: About 200g
  • Dimension: 78mmx64mmx31mm

Packaging & Delivery

Delivery Detail: 3 days after receive payment

ETCR025 Split Type High Accuracy Leakage current Sensor









ETCR025 Split Type High Accuracy Leakage Current Sensor  Introduction

ETCR025 Split Type High Accuracy Leakage current Sensoris used for measurement of high accuracy AC current, leakage current, high order harmonic current, phase, power energy, power, power factor. Adopt the latest CT technology. It is portable, large clamp design, no need to disconnect the measured circuits, non-contact, safe and fast. It can be connected with phase detection analyzer, industrial control equipment, data recorder, oscilloscope, harmonic analyzer, electric power quality analyzer, high precision digital multi-meter, etc. Widely applied in electricity, communication, meteorology, railway, oilfield, construction, measurement, scientific and research teaching unit, industrial and mining enterprises.
ETCR025 Split Type High Accuracy Leakage current Sensor’score is made of special alloy, adopt the double magnetic shielding techniques, can almost shield the influence from external magnetic field, to ensure the high precision, high stability and high reliability of perennial uninterrupted measurement.

ETCR025 Split Type High Accuracy Leakage Current Sensor Technical Specifications
Function
Measurement of AC current, leakage current, high order harmonic current, phase, power energy, power, power factor
Test mode
Split Type CT
CT Size
Φ25mm(available for line $25mm)
Range
0.000mA~60A (AC)
Resolution
1uA (AC)
Accuracy
±1.0%FS(23℃±2℃, below 70%RH, keep the wire be in the center of clamp)
Coils Turn
Standard 800:1(Customize is allowed)
Phase Error
≤2℃(50Hz/60Hz; 23℃±2℃)
Reference Load
RL: 0~600mA≤100ohm; 0-6A≤10ohm; 0-60A≤1ohm;
Output Mode
Current induction output(Take the voltage can be an external load resistance (RL)
Output Interface
3.5mm audio plug(tail plug, banana pin, or BNC pin)
Output Wire Length
2m(Customize is allowed)
Electric Field Interference
About 5mA when the external electric field 100A, 10mm nearby
Measured Wire Position
Approximately in the center of the closed core
Current Frequency
45HZ-60Hz(when measuring big current)
Frequency Feature
10Hz~100kHz
Voltage of circuit
Below AC 600V
Dimension
78mmx64mmx31mm
Weight
About 200g
Working Environment
-20℃ ~ 50℃; below 80%rh
Storage Environment
-10℃ ~60℃; below 70%rh
Insulation Strength
AC 2KV/rms.(between the core and shell)
Safety Rules
IEC1010-1,IEC1010-2-032,Pollution degree:2 CAT Ⅲ(600V)



Packing Case Size(L×W × H): 16×8×5(cm)

Weight: 0.5Kg



Company information

ETCR

A professional manufacturer of test and measure instrument
We have our research and development, top sales group, supply application services
 has become well-known brand
ETCR Help you work safer and faster
There will be professional responsible for after sale service
We are developing international market
So every customer's identity is our best encouragement
Our buyers have stayed with us for 12 years
ISO Patentand CE certificate
OEM services available


More information, please kindly view our web site: http://www.etcr.cc/en/

Online store: http://www.aliexpress.com/store/1119041
